Name: HCP-173400-R | HCP-173400-R-ND | HCP-173400-R-DALI - White Rectangle 40w LED Panel
Brand: Havit Commercial
SKU: HCP-173400-R
Availability: InStock

HCP-173400-R | HCP-173400-R-ND | HCP-173400-R-DALI - White Rectangle 40w LED Panel

Rectangle LED Panel
White trim
120° Beam angle
IP rating: IP20
Triac Dimmable / Dali 2 Dimmable / Non Dimmable
TRI Colour - 3000k, 4000k, 5000k
CRI 90+
UGR<24
Input voltage: 240v AC
Built-in 40w LED
5 years replacement warranty

Recessed and Surface Mount Kits Available - View Here

Product Details

Part Number	Colour Temp	Lumens	Included LED	Dimming
HCP-173400-R	3000k 4000k 5000k	2900lm 3100lm 3300lm	40w 240v Built in LED	Triac Dimming
HCP-173400-R-ND	3000k 4000k 5000k	2900lm 3100lm 3300lm	40w 240v Built in LED	Non Dimming
HCP-173400-R-DALI	3000k 4000k 5000k	2900lm 3100lm 3300lm	40w 240v Built in LED	Dali 2 Dimming

Data Sheet

IES Files

Install Sheet

Installation Instructions

Downloads
