Name: HCP-173400-S | HCP-173400-S-ND | HCP-173400-S-DALI - White Square 40w Tri Colour LED Panel
Brand: Havit Commercial
SKU: HCP-173400-S
Availability: InStock

HCP-173400-S | HCP-173400-S-ND | HCP-173400-S-DALI - White Square 40w Tri Colour LED Panel

Square LED Panel
White trim
120° Beam angle
IP Rating: IP20
Triac Dimmable | Non-Dimmable | Dali 2
TRI Colour - 3000k, 4000k, 5000k
CRI 90+
UGR<24
Input voltage: 240v AC
Built-in 40w LED
5 years replacement warranty

Recessed and Surface Mount Kits Available - View Here

Product Details

Part Number	Colour Temp	Lumens	Included LED	Dimming
HCP-173400-S	3000k 4000k 5000k	2900lm 3100lm 3300lm	40w 240v Built in LED	Triac Dimming
HCP-173400-S-ND	3000k 4000k 5000k	2900lm 3100lm 3300lm	40w 240v Built in LED	Non Dimming
HCP-173400-S-DALI	3000k 4000k 5000k	2900lm 3100lm 3300lm	40w 240v Built in LED	Dali 2 Dimming

Data Sheet

IES Files

Install Sheet

Installation Instructions

Downloads
